PNP Plastic-Encapsulate Transistor

TO-92

KSA708

WEITRON

Lead(Pb)-Free

P b

1. EMITTER

2. COLLECTOR

3. BASE

FEATURES :

• Low Saturation Medium Current Application

Symbol

Parameter

Value

Units

Collector-Base Voltage

ELECTRICAL CHARACTERISTICS (Tamb=25°C unless otherwise specified)

Parameter

Symbol

Test conditions

MIN

Units

MAX

TYP

Collector-Emitter Voltage

Emitter-Base Voltage

Collector Current -Continuous

Collector Power Dissipation

Thermal Resistance From Junction To Ambient

Junction Temperature

Storage Temperature

Tstg

-80

-60

-8

-0.7

0.8

156

150

-55 to +150

V

V

V

A

W

°C/W

°C

°C

Collector-base breakdown voltage

Collector-emitter breakdown voltage

Emitter-base breakdown voltage

Collector cut-off current

Emitter cut-off current

Collector-emitter saturation voltage

Base-emitter saturation voltage

Transition Frequency

Collector output capacitance

DC current gain

-80

-60

-8

-0.1

-0.1

240

-0.7

-1.1

50

40

13

V

V

V

µA

µA

V

V

pF

MHz

Y

O

R

Rank

Range

120-240

70-140

40-80

f=1MHz
