Inchange Semiconductor

Product Specification

Silicon NPN Power Transistors

2SC2921

DESCRIPTION

・With MT-200 package

・Complement to type 2SA1215

APPLICATIONS

・Audio and general purpose

PINNING(see Fig.2)

DESCRIPTION

1

Base

2

Collector;connected to

mounting base

3

Emitter

Absolute maximum ratings(Ta=25℃)

SYMBOL

PARAMETER

CONDITIONS

VALUE

UNIT

VCBO

Collector-base voltage

Open emitter

160

V

VCEO

Collector-emitter voltage

Open base

160

V

VEBO

Emitter-base voltage

Open collector

5

V

IC

Collector current

15

A

IB

Base current

4

A

PC

Collector power dissipation

TC=25℃

150

W

Tj

Junction temperature

150

℃

Tstg

Storage temperature

-55~150

℃

Fig.1 simplified outline (MT-200) and symbol
