background image
Stainless Steel Package
Semiconductor Group
1
02.97
Silicon Piezoresistive
Relative Pressure Sensor
KPY 51-R
KPY 56-R
Features
• Low pressure and temperature hysteresis
• Fast response
• High sensitivity and linearity
• Fatigue free monocrystaline silicon diaphragm
giving high load cycle stability
• High long term stability
• Built in silicon temperature sensor
• Media compatible stainless housing
Type and
Marking
Symbol
Pressure Range
Unit
Ordering Code
KPY 51 R
P
0 … PN
0
… 0.25
bar
Q62705-K174
KPY 52 R
0
… 0.6
Q62705-K171
KPY 53 R
0
… 1.6
Q62705-K176
KPY 54 R
0
… 4
Q62705-K178
KPY 55 R
0
… 10
Q62705-K180
KPY 56 R
0
… 25
Q62705-K182
Pin Configuration
1
Capillary tube
2+
V
IN
3
− V
OUT
4
Temperature sensor
(typ.
R
25 = 2 kΩ)
5
Temperature sensor
6
− V
IN
7+
V
OUT
8
Not connected
