background image
U74LVC1G08
CMOS IC
UNISONICTECHNOLOGIESCO.,LTD
4 of 5
www.unisonic.com.tw
QW-R502-223.E
DYNAMIC CHARACTERISTICS (TA=25℃)
PARAMETER
SYMBOL
TEST CONDITIONS
MIN
TYP
MAX
UNIT
Propagation delay from
input (A or B) to output(Y)
tPLH/tPHL
VCC=1.8V±0.15V, CL=15pF
1.5
7.2
ns
VCC=2.5V±0.2V, CL=15pF
0.7
4.4
ns
VCC=3.3V±0.3V, CL=15pF
0.8
3.6
ns
VCC=5V±0.5V, CL=15pF
0.8
3.4
ns
VCC=1.8V±0.15V, CL=30 or 50pF
2.4
8
ns
VCC=2.5V±0.2V, CL=30 or 50pF
1.1
5.5
ns
VCC=3.3V±0.3V, CL=30 or 50pF
1
4.5
ns
VCC=5V±0.5V, CL=30 or 50pF
1
4
ns
OPERATING CHARACTERISTICS (TA=25℃)
PARAMETER
SYMBOL
TEST CONDITIONS
MIN
TYP
MAX
UNIT
Power Dissipation
Capacitance
CPD
VCC=1.8V, f=10MHz
21
pF
VCC=2.5V, f=10MHz
24
pF
VCC=3.3V, f=10MHz
26
pF
VCC=5V, f=10MHz
31
pF
