ADRF6704

Data Sheet

Rev. 0 | Page 12 of 36

–160

–150

–140

–130

–120

–110

–100

–90

–80

–70

–60

–50

–40

–30

–20

–10

100

1000

10000

100000

OFFSET FREQUENCY (kHz)

2.5kHz LOOP FILTER

130kHz LOOP FILTER

–40°C

+25°C

+85°C

Figure 16. Phase Noise vs. Offset Frequency and Temperature,

fLO = 2500 MHz

–160

–150

–140

–130

–120

–110

–100

–90

–80

–70

–60

–50

–40

–30

–20

–10

100

1000

10000

100000

OFFSET FREQUENCY (kHz)

2.5kHz LOOP FILTER

130kHz LOOP FILTER

–40°C

+25°C

+85°C

Figure 17. Phase Noise vs. Offset Frequency and Temperature,

fLO = 2700 MHz

–160

–150

–140

–130

–120

–110

–100

–90

–80

–70

–60

–50

–40

–30

–20

–10

100

1000

10000

100000

OFFSET FREQUENCY (kHz)

2.5kHz LOOP FILTER

130kHz LOOP FILTER

–40°C

+25°C

+85°C

Figure 18. Phase Noise vs. Offset Frequency and Temperature,

fLO = 2900 MHz

LO FREQUENCY (MHz)

0.1

0.2

0.3

0.4

0.5

0.6

0.7

0.8

0.9

1.0

2500

2550

2600

2650

2700

2750

2800

2850

2900

–40°C

+25°C

+85°C

Figure 19. Integrated Phase Noise vs. LO Frequency

LO FREQUENCY (MHz)

–150

–140

–130

–120

–110

–100

–90

–80

2500

2550

2600

2650

2700

2750

2800

2850

2900

OFFSET = 1kHz

OFFSET = 5MHz

OFFSET = 100kHz

–40°C

+25°C

+85°C

Figure 20. Phase Noise vs. LO Frequency at 1 kHz, 100 kHz, and 5 MHz Offsets

LO FREQUENCY (MHz)

–150

–140

–130

–120

–110

–100

–90

–80

2500

2550

2600

2650

2700

2750

2800

2850

2900

OFFSET = 1MHz

OFFSET = 10kHz

–40°C

+25°C

+85°C

Figure 21. Phase Noise vs. LO Frequency at 10 kHz and 1 MHz Offsets
