TEST CIRCUIT AND WAVEFORM
Figure 1
VGS
RGEN
VDD
VIN
RL
VOUT
DUT
G
D
S
Pulse Width
Input, Vin
Output, Vout
ton
toff
td(off)
tr
td(on)
tf
Inverted
10%
10%
10%
50%
50%
90%
90%
90%
Figure 2. Switching Waveforms
AMS 2N7002
3
Advanced Monolithic Systems http://www.ams-semitech.com
