This is information on a product in full production.

March 2012

Doc ID 022580 Rev 1

1/45

1

M95160 M95160-W M95160-R M95160-F

16-Kbit serial SPI bus EEPROM with high-speed clock

Datasheet

−production data

Features

■ Compatible with the Serial Peripheral Interface

(SPI) bus

■ Memory array

– 16 Kb (2 Kbytes) of EEPROM

– Page size: 32 bytes

■ Write

– Byte Write within 5 ms

– Page Write within 5 ms

■ Write Protect: quarter, half or whole memory

array

■ High-speed clock: 10 MHz

■ Single supply voltage:

– 4.5 V to 5.5 V for M95160

– 2.5 V to 5.5 V for M95160-W

– 1.8 V to 5.5 V for M95160-R

– 1.7 V to 5.5 V for M95160-F

■ Operating temperature range: from -40°C up to

+85°C

■ Enhanced ESD protection

■ More than 1 million Write cycles

■ More than 40-year data retention

■ Packages

– RoHS compliant and halogen-free

(ECOPACK®)

SO8 (MN)

150 mil width

TSSOP8 (DW)

169 mil width

WLCSP (CS)

UFDFPN8 (MB, MC)

2 × 3 mm (MLP)

(preliminary data)

www.st.com
