1000

800

600

400

200

2.8

3.0

3.2

2.9

3.1

3.3

3.4

3.5

VRMS (V)

REPRESENTS 4500 PARTS

Figure 27. Distribution of VRMS, PIN = −10 dBm, 900 MHz

1000

800

600

400

200

0.8

0.9

1.0

1.1

1.2

1.3

1.4

1.5

VRMS (V)

REPRESENTS 4500 PARTS

Figure 28. Distribution of VRMS, PIN = −45 dBm, 900 MHz

0.5

1.0

1.5

2.0

2.5

3.0

3.5

4.0

4.5

5.0

5.5

6.0

TIME (µs)

RF BURST PULSE

0dBm

–10dBm

–20dBm

–30dBm

–40dBm

Figure 29. Output Response to RF Burst Input, Carrier Frequency = 2.14 GHz,

CRMS = 1 nF

0.5

1.0

1.5

2.0

2.5

3.0

3.5

4.0

4.5

5.0

5.5

6.0

TIME (ms)

0.5

1.0

1.5

2.0

2.5

3.0

3.5

4.0

4.5

5.0

RF BURST PULSE

0dBm

–10dBm

–20dBm

–30dBm

–40dBm

Figure 30. Output Response to RF Burst Input, Carrier Frequency = 2.14 GHz,

CRMS = 0.1 µF

0.5

1.0

1.5

2.0

2.5

3.0

3.5

4.0

4.5

5.0

5.5

6.0

TIME (µs)

0dBm

–10dBm

–20dBm

–30dBm

–40dBm

TADJ/PWDN

PULSE

Figure 31. Output Response Using Power-Down Mode for Various RF Input

Levels, Carrier Frequency = 2.14 GHz, CRMS = 1 nF

0.5

1.0

1.5

2.0

2.5

3.0

3.5

4.0

4.5

5.0

5.5

6.0

0.5

1.0

1.5

2.0

2.5

TIME (ms)

TADJ/PWDN

PULSE

0dBm

–10dBm

–20dBm

–30dBm

–40dBm

Figure 32. Output Response Using Power-Down Mode for Various RF Input

Levels, Carrier Frequency = 2.14 GHz, CRMS = 0.1 µF
