7 / 40 page

ADRF6750

Rev. A | Page 7 of

ABSOLUTE MAXIMUM RATINGS

Table 4.

Parameter

Rating

Supply Voltage VCC1, VCC2, VCC3, and VCC4

−0.3 V to +6 V

Supply Voltage VREG1, VREG2, VREG3, VREG4,

VREG5, and VREG6

−0.3 V to +4 V

IBBP, IBBN, QBBP, and QBBN

0 V to 2.5 V

Digital I/O

−0.3 V to +4 V

Analog I/O (Other Than IBBP, IBBN, QBBP,

and QBBN)

−0.3 V to +4 V

TESTLO, TESTLO Difference

1.5 V

θJA (Exposed Paddle Soldered Down)

26°C/W

Maximum Junction Temperature

120°C

Storage Temperature Range

−65°C to +150°C

Stresses above those listed under Absolute Maximum Ratings

may cause permanent damage to the device. This is a stress

rating only; functional operation of the device at these or any

other conditions above those indicated in the operational

section of this specification is not implied. Exposure to absolute

maximum rating conditions for extended periods may affect

device reliability.

ESD CAUTION
