4 / 24 page

AD8305

Rev. B | Page 4 of 24

ABSOLUTE MAXIMUM RATINGS

Table 2.

Parameter

Rating

Supply Voltage VP − VN

12 V

Input Current

20 mA

Internal Power Dissipation

500 mW

θJA1

30°C/W

Maximum Junction Temperature

125°C

Operating Temperature Range

−40°C to +85°C

Storage Temperature Range

−65°C to +150°C

Lead Temperature (Soldering 60 sec)

300°C

1 With package die paddle soldered to thermal pad containing nine vias

connected to inner and bottom layers.

Stresses above those listed under Absolute Maximum Ratings

may cause permanent damage to the device. This is a stress

rating only; functional operation of the device at these or any

other conditions above those indicated in the operational

section of this specification is not implied. Exposure to absolute

maximum rating conditions for extended periods may affect

device reliability.
