LM2671

www.ti.com

SNVS008K – SEPTEMBER 1998 – REVISED APRIL 2013

Table 10. Output Capacitor Selection Table (continued)

Output Capacitor

Surface Mount

Through Hole

Cap.

Sprague

AVX TPS

Sanyo OS-CON

Sanyo MV-GX

Nichicon

Panasonic

Ref.

Desg.

594D Series

Series

SA Series

Series

PL Series

HFQ Series

#

(

μF/V)

(

μF/V)

(

μF/V)

(

μF/V)

(

μF/V)

(

μF/V)

C3

120/6.3

100/10

100/35

120/35

120/35

120/35

C4

68/10

100/10

68/10

220/35

220/35

220/35

C5

100/16

100/10

100/10

150/35

150/35

150/35

C6

100/16

100/10

100/10

120/35

120/35

120/35

C7

68/10

100/10

68/10

150/35

150/35

150/35

C8

100/16

100/10

100/10

330/35

330/35

330/35

C9

100/16

100/16

100/16

330/35

330/35

330/35

C10

100/16

100/16

68/16

220/35

220/35

220/35

C11

100/16

100/16

68/16

150/35

150/35

150/35

C12

100/16

100/16

68/16

120/35

120/35

120/35

C13

100/16

100/16

100/16

120/35

120/35

120/35

C14

100/16

100/16

100/16

220/35

220/35

220/35

C15

47/20

68/20

47/20

220/35

220/35

220/35

C16

47/20

68/20

47/20

150/35

150/35

150/35

C17

47/20

68/20

47/20

120/35

120/35

120/35

C18

68/25

(2×) 33/25

220/35

220/35

220/35

C19

33/25

33/25

150/35

150/35

150/35

C20

33/25

33/25

120/35

120/35

120/35

C21

33/35

(2×) 22/25

(2)

150/35

150/35

150/35

C22

33/35

22/35

(2)

120/35

120/35

120/35

C23

(2)

(2)

(2)

220/50

100/50

120/50

C24

(2)

(2)

(2)

150/50

100/50

120/50

C25

(2)

(2)

(2)

150/50

82/50

82/50

(1)

The SC series of Os-Con capacitors (others are SA series)

(2)

The voltage ratings of the surface mount tantalum chip and Os-Con capacitors are too low to work at these voltages.

Application Information

TYPICAL SURFACE MOUNT PC BOARD LAYOUT, FIXED OUTPUT (4X SIZE)

D1 - 1A, 40V Schottky Rectifier, Surface Mount

L1 - 47

μH, L13, Coilcraft DO3308
