E5AK

2

Ordering Information

■ List of Models

Note: 1. When using the heater burnout alarm function with a standard model, the Linear Output Unit cannot be used for the control outputs (heat).

2. Be sure to specify the Current Transformer, Output Unit, and Option Unit when ordering.

3. The Digital Controller provides transfer outputs at 4 to 20 mA for the PV and other values and control outputs at 4 to 20 mA for the current

outputs.

Note: The Digital Controller uses a dedicated, high-resolution Output Unit. The E53-C Current Output Unit for the E5

@X cannot be used with the

Digital Controller.

Note: 1. The Option Unit can be used either by the E5AK or E5EK.

2. The E5AK allows a maximum of three Option Units to be mounted. Refer to page 8 for mounting combinations.

The E5EK allows only one Option Unit to be mounted.

Inspection Report

The Digital Controller can be provided together with an inspection report.

Refer to the following legend with the suffix “K” when ordering a model provided together with an inspection report.

E5

@K-AA2-K, E5@K-PRR2-K, E5@K-TAA2-K, E5@K-TPRR2-K, E53-AKF-K

Description

Model

Specification

Base Unit

E5AK-AA2 AC100-240

Standard model

E5AK-AA2-500 AC100-240

Standard model with terminal cover

E5AK-PRR2 AC100-240

Position-proportional model

E5AK-PRR2-500 AC100-240

Position-proportional model with terminal cover

E5AK-TAA2 AC100-240

Standard model

E5AK-TAA2-500 AC100-240

Standard model with terminal cover

E5AK-TPRR2 AC100-240

Position-proportional model

E5AK-TPRR2-500 AC100-240

Position-proportional model with terminal cover

Description

Model

Specification

Output Unit

E53-R

Relay

E53-S

SSR

E53-Q

Pulse (NPN) 12 VDC

E53-Q3

Pulse (NPN) 24 VDC

E53-Q4

Pulse (PNP) 24 VDC

E53-C3

Linear (4 to 20 mA)

E53-C3D

Linear (0 to 20 mA)

E53-V34

Linear (0 to 10 V)

E53-V35

Linear (0 to 5 V)

Description

Model

Specification

Option Unit

E53-AKB

Event input

E53-EN01

Communication (RS-232C)

E53-EN02

Communication (RS-422)

E53-EN03

Communication (RS-485)

E53-AKF

Transfer output
