EM260
120-0260-000M Rev 1.1
Page 36
The UART signals follow the usual conventions:
When idle, serial data is high (marking)
The start bit is low (spacing), and the stop bit is high (marking)
Data bits are sent least-significant bit first, with positive (non-inverting) logic
The flow control signals are asserted low
Note that commonly used EIA transceivers invert these logic levels.
Silicon Labs supplies the UART Gateway protocol software in two versions: one uses RTCS/CTS flow control and
the other uses XON/XOFF. The UART is set up as follows for these versions:
115,200 bps for the RTS/CTS version
57,600 bps for the XON/XOFF version
No parity bit
8 data bits
1 stop bit
The ASH protocol has been tuned for optimal operation with the two configurations listed here. These
configurations can be changed through manufacturing tokens, but doing so may result in a degradation of
performance. To learn how to change the configuration, contact customer support at www.silabs.com/zigbee-
support.
