NTE Series

Isolated 1W Single Output SM DC/DC Converters

KDC_NTE.K04 Page 6 of 6

www.murata-ps.com/support

Murata Power Solutions, Inc. makes no representation that the use of its products in the circuits described herein, or the use of other

technical information contained herein, will not infringe upon existing or future patent rights. The descriptions contained herein do not imply

the granting of licenses to make, use, or sell equipment constructed in accordance therewith. Specifications are subject to change without

notice.

© 2014 Murata Power Solutions, Inc.

Murata Power Solutions, Inc.

11 Cabot Boulevard, Mansfield, MA 02048-1151 U.S.A.

ISO 9001 and 14001 REGISTERED

TAPE & REEL SPECIFICATIONS

REEL OUTLINE DIMENSIONS

TAPE OUTLINE DIMENSIONS

REEL PACKAGING DETAILS

13.20

(0.52)

0.60 (0.02) MAX

16.00 (0.63)

6.60

(0.26)

11.60

(0.46)

1.75(0.07)

11.50

(0.45)

24.00±0.30

(0.94±0.04)

4.00

(0.16)

2.00

(0.08)

1.50 (Ø0.06)

-0.00 (-0.00)

+0.004 (+0.10)

330

(12.99) MAX

100

(3.94) MIN

13.00±0.25

(0.51±0.009)

Ø

Ø

TRAILER SECTION

160 (6.30) MIN

GOODS ENCLOSURE

SECTION

LEADER SECTION

400 (15.75) MIN

CARRIER TAPE START

100 (3.94) MIN

Product Orientation

Pin 1, located nearest to

carrier drive sprocket.

Reel Quantity : 500
