background image
Pin Descriptions
PIN
TYPE
DESCRIPTION
SD15 - SD0
I/O
Data bus
SA1 - SA0
I
Address
CS
I
Chip select (active low)
IOW
I
Write strobe (active low)
IOR
I
Read strobe (active low)
SBHE
I
System High Byte Enable (active low)
IOCS16
OC
Indicates that the access register can support 16 bit transfer.
DRQP
O
DMA Request (play channel)
DRQR
O
DMA Request (record channel)
DACKP
I
DMA Acknowledge (play channel)
DACKR
I
DMA Acknowledge (record channel)
TC
I
DMA terminal count
IRQ
O
Interrupt request (active high, open drain)
RESET
I
Reset (active high)
XTLI
I
Crystal oscillator
XTLO
O
Crystal oscillator
PWRDN
I
Power-down (active low)
AUDIOIN
AI
Audio buffer input
ADCIN
AO
Audio buffer output/input to ADC
DACOUT
AO
DAC audio output
BUFIN
AI
Uncommitted audio buffer input
BUFOUT
AO
Uncommitted audio buffer output
VDD
P
Digital +5V supply
VDDA
P
Analog +5V supply
VDDP
P
Digital +5V supply
VSS
P
Digital GND
VSSA
P
Analog GND
VSSP
P
Digital GND
ICS2002
2
