BCX53

PNP Transistors

Plastic-Encapsulate Transistors

RoHS Compliant Product

A suffix of "-C" specifies halogen & lead-free

Elektronische Bauelemente

1.BASE

2.COLLECTOR

3.EMITTER

1

2

3

Features

Any changing of specification will not be informed individual

http://www.SeCoSGmbH.com

01-Jun-2005 Rev. B

Page 1 of 2

4.4~4.6

1.4~1.8

0.35~0.44

1.4~1.6

0.32~0.52

0.36~0.56

1.5Ref.

2.9~3.1

Dimensision in Millimeter

SOT-89

C

o

W (Tamb=25 )

A

V

Power dissipation

PCM:

0.5

Collector current

ICM:

-1.0

Collector-base voltage

V(BR)CBO:

-100.0

Operating and storage junction temperature range

TJ，Tstg: 150, -65 ~ 150 C

ELECTRICAL CHARACTERISTICS (Tamb=25

unless otherwise specified)

PARAMETER

SYMBOL

TEST CONDITIONS

hFE(1)

VCE=-2V, IC=- 5 mA

- 150 mA

63

DC current gain

hFE(3)

VCE=-2V, IC= -500mA

40

hFE(2)

VCE=-2V, IC=

63

250

Base-emitter

voltage

VBE

IC= -500 mA, VCE=-2V

-1

V

MIN

MAX

UNIT

C

o

Collector-base breakdown voltage

V(BR)CBO

Ic=-100µA , IE=0

-100

V

IB=0

-80

-5

Collector-emitter breakdown voltage

V(BR)CEO

IC=- 1 mA ,

V

Emitter-base breakdown voltage

V(BR)EBO

IE=-100 µA, IC=0

V

Collector cut-off current

ICBO

VCB=-30V, IE=0

-0.1

µA

Emitter cut-off current

IEBO

VEB=-5V, IC=0

-0.1

µA

Collector-emitter saturation voltage

VCE(sat)

IC=-500 mA, IB=- 50mA

-0.5

V

Transition frequency

f T

VCE= -5V, IC=-10mA

f = 100MHz

50

MHz

DEVICE MARKING

BCX53=AH

BCX53-10=AK

BCX53-16=AL
