ES2J
DIODE
UNISONICTECHNOLOGIESCO.,LTD
3 of 4
www.unisonic.com.tw
QW-R601-268.A
TYPICAL CHARACTERISTICS
Forward Current Derating Curve
2
1.6
1.2
0.8
0
0
25
50
75
100 125 150
175
Single Phase
Half Wave 60Hz
Resistive or
inductive Load
Ambient Temperature (°C)
Maximum Non-Repetitive Peak Forward Surge Current
50
40
30
20
10
0
1
10
100
Number of Cycles aT 60Hz
8.3ms Single
Half Sine-Wave
(JEDEC Method)
0.4
Typical Instantaneous Forward Characteristics
20
10
1
0.1
0.01
0
0.4
0.8
1.2
1.6 1.8
Instantaneous Forward Voltage (V)
TJ=25°C
Pulse Width=300s
1% Duty Cycle
Typical Reverse Characteristics
1,000
100
10
1
0.1
0.01020
40
60
80
100
Percent of Peak Reverse Voltage (%)
TJ=25°C
TJ=100°C
Typical Junction Capacitance
200
100
10
1
0.1
1.0
10
100
Reverse Voltage (V)
TJ=25°C
Typical Transient Thermal Impedance
100
10
1
0.1
0.01
0.1
1
10
100
t, Pulse Duration (sec.)
