RS1M

DIODE

UNISONICTECHNOLOGIESCO.,LTD

2 of 4

www.unisonic.com.tw

QW-R601-210.B



ABSOLUTE MAXIMUM RATINGS (TA=25°C, unless otherwise specified)

Single phase half-wave 60Hz, resistive or inductive load, for capacitive load current derate by 20%.

PARAMETER

SYMBOL

RATINGS

UNIT

Repetitive Peak Reverse Voltage

VRRM

1000

RMS Voltage

VRMS

700

DC Blocking Voltage

VDC

1000

Average Forward Rectified Current at TL=90°C

1.0

Peak Forward Surge Current 8.3ms Single Half

Sine-Wave Superimposed on Rated Load

(JEDEC Method)

IFSM

30.0

Junction Temperature

-65~+150

°C

Storage Temperature

TSTG

-65~+150

°C

Note: Absolute maximum ratings are those values beyond which the device could be permanently damaged.

Absolute maximum ratings are stress ratings only and functional device operation is not implied.



THERMAL DATA

PARAMETER

SYMBOL

RATINGS

UNIT

Junction to Ambient (Note)

θJA

°C/W

Note: 8.0mm

2 (0.13mm thick) land pads.



ELECTRICAL CHARACTERISTICS (TA=25°C, unless otherwise specified)

Single phase half-wave 60Hz, resistive or inductive load, for capacitive load current derate by 20%.

PARAMETER

SYMBOL

TEST CONDITIONS

MIN TYP MAX UNIT

Instantaneous Forward Voltage

IF=1.0A

1.3

DC Reverse Current at Rated DC Blocking

Voltage

TA=25°C

5.0

μA

TA=100°C

50.0

μA

Reverse Recovery Time

trr

IF=0.5A, IR=1.0A,

Irr=0.25A

500

Junction Capacitance (Note)

15.0

Note: Measured at 1MHz and applied reverse voltage of 4.0V D.C.
