ABSOLUTE MAXIMUM RATINGS

Table 4.

Parameter

Rating

Operating Temperature

−40°C to +150°C

Storage Temperature

−65°C to +150°C

Supply Voltage (VDD)1

−0.3 V to +6 V

Output Short-Circuit Duration to GND or VDD

Indefinite

VTEMP Short-Circuit to GND or VDD

Indefinite

ESD

Human Body Model (HBM)2

4000 V

Machine Model (MM)3

300 V

Charge Device Model (CDM)4

1250 V

GC or PD at VDD + 0.3 V.

Applicable standard: JESD22-C101.

Applicable standard: JESD22-A115.

Applicable standard: ESDA/JEDEC JS-001-2011.

Stresses at or above those listed under Absolute Maximum

Ratings may cause permanent damage to the product. This is a

stress rating only; functional operation of the product at these

or any other conditions above those indicated in the operational

section of this specification is not implied. Operation beyond

the maximum operating conditions for extended periods may

affect product reliability.

THERMAL RESISTANCE

θJA is specified for the worst case conditions, that is, a device

soldered in a circuit board for surface-mount packages.

Table 5. Thermal Resistance

Package Type

θJA

Unit

8-Lead SOIC

120

°C/W
