Inductors for Power Circuits

Wound Ferrite

FEATURES

Magnetic shield type wound inductor for power circuits.

Low-profile product.

High magnetic shield construction and compatible with high-density mounting.

APPLICATION

Smart phones, tablet terminals, HDDs, SSDs, DVCs, DSCs, mobile display panels, portable game devices, compact power supply

modules, other

PART NUMBER CONSTRUCTION

OPERATING TEMPERATURE RANGE, PACKAGE QUANTITY, PRODUCT WEIGHT

Product compatible with RoHS directive

Halogen-free

Compatible with lead-free solders

Overview of VLS252012E Type

VLS

252012

E

T

-

R47

N

Series name

L×W×H Dimensions

internal code

Packaging style

Inductance

Inductance

tolerance

(mm)

(μH)

252012

2.5×2.0×1.2

T

Taping

R47

0.47

M

±20%

2R2

2.2

N

±30%

100

10

Type

Temperature range

Package quantity

Individual weight

Operating

（°C）

Storage

（°C）

(pieces/reel)

（mg）

VLS252012E

–40 to +105

–40 to +105

2000

24

RoHS Directive Compliant Product: See the following for more details related to RoHS Directive compliant products. http://product.tdk.com/en/environment/rohs/

Halogen-free: Indicates that Cl content is less than 900ppm, Br content is less than 900ppm, and that the total Cl and Br content is less than 1500ppm.
