AB08X5 Real-Time Clock Family
Date of Issue: October 16, 2014
3.0 x 3.0 mm
Page 19 of 33
Abracon Drawing #453567
Revision: C
Figure 12 shows the typical VBAT power state operating current vs. temperature in RC mode.
Figure 12. Typical VBAT Current vs. Temperature in RC Mode
Figure 13 shows the typical VBAT power state operating current vs. temperature in RC Autocalibration
mode.
Figure 13. Typical VBAT Current vs. Temperature in RC Autocalibration Mode
5
15
25
35
45
55
65
75
‐40
‐30
‐20
‐10
0
10
20
304050607080
Temperature  (°C)
VBAT = 1.8V
VBAT = 3.0V
TA = 25 °C
5
10
15
20
25
30
35
40
45
50
55
‐40
‐30
‐20
‐10
0
10203040
50
6070
Temperature (°C)
VBAT = 1.8V
VBAT = 3.0V
TA = 25 °C
