RJ45 Low Profile, Style 4 Shield

RJ45 Low Profile PC Board Layout

.700

17.78

7

5

3

1

8

6

4

2

.515*

13.08 .010

.25

.165

4.19

.630

16.00

.430

10.92

.217

5.51

.135

3.43

.120

3.05

.740

18.80

*to top of shield

.450

11.43

Dia.

(8 Places)

.128±.003

3.25±.08

.076±.003

1.93±.08

(2 Places)

1

3

5

7

2

4

6

8

.120

3.05

.217

5.51

.350

8.89

.050

1.27

.050

1.27

.030 +.008/-.003

.76 +.20/-.08

.250

6.35

.095

2.41

(7 Spaces)

(2 Places)

Dia.

Dia.

Part No.

RJ45-8N4-B

RJ45-8N4-S

RJ45-8Z4

For all RJ45 N and Z Series Models

Shown from Component Side

      
