Copyright © 2013-2016 Cree, Inc. All rights reserved. The information in this document is subject to change without notice. Cree®, XLamp® and EasyWhite® are registered trademarks and the Cree logo is a

trademark of Cree, Inc. UL® and the UR logo are registered trademarks of UL LLC.

XLamp® mK-R2 LED

CREE EAsywhitE® bins PLottED on thE 1931 CiE CoLoR sPACE (t

J = 85 °C)

bin AnD oRDER CoDE FoRMAts

Bin codes and order codes are configured as follows.

order Code

bin Code

SSSCCC-HH-HHHH-GHKLNNNNN

Series = MKR

Internal code

Forward voltage class

N: Default (36 V)

CRI specification

H: 80-CRI minimum

Kit code

Internal code

Color

BWT = White

SSSCCC-E-DDD-MM-HK-L-PP

Series = MKR

Internal code

Luminous flux group

Internal code

CRI specification

H: 80-CRI minimum

Forward voltage class

N: Default (36 V)

Chromaticity bin

Color

BWT = White
