8 / 25 page

AD8227

Rev. 0 | Page 7 of

ABSOLUTE MAXIMUM RATINGS

Table 4.

Parameter

Rating

Supply Voltage

±18 V

Output Short-Circuit Current

Indefinite

Maximum Voltage at −IN or +IN

−VS + 40 V

Minimum Voltage at −IN or +IN

+VS − 40 V

REF Voltage

±VS

Storage Temperature Range

−65°C to +150°C

Operating Temperature Range

−40°C to +125°C

Maximum Junction Temperature

140°C

Stresses above those listed under Absolute Maximum Ratings

may cause permanent damage to the device. This is a stress

rating only; functional operation of the device at these or any

other conditions above those indicated in the operational

section of this specification is not implied. Exposure to absolute

maximum rating conditions for extended periods may affect

device reliability.

THERMAL RESISTANCE

θJA is specified for a device in free air.

Table 5.

Package

θJA

Unit

8-Lead MSOP, 4-Layer JEDEC Board

135

°C/W

8-Lead SOIC, 4-Layer JEDEC Board

121

°C/W

ESD CAUTION
