AD9142A
Data Sheet
Pin No.
Mnemonic
Description
71
CVDD18
1.8 V Clock Supply. Pin 71 supplies the clock receivers, clock multiplier, and clock distribution.
72
CVDD18
1.8 V Clock Supply. Pin 72 supplies the clock receivers, clock multiplier, and clock distribution.
EPAD
Exposed Pad. The exposed pad (EPAD) must be soldered to the ground plane (AVSS, DVSS, CVSS). The
EPAD provides an electrical, thermal, and mechanical connection to the board.
