Technical Data Sheet

PROTECTION CAP

170-XXX-XXXXX

Rosenberger Hochfrequenztechnik GmbH & Co. KG

P.O.Box 1260

D-84526 Tittmoning

Germany

www.rosenberger.de

Tel.

: +49 8684 18-0

Email : info@rosenberger.de

Page

2 / 2

170-089-00000

2,36x4,76x0,71

black

Mini Coax (f + m)

170-097-00000

26,99x12,70x1,52

black

HVR40 Kabelseite

170-097-00001

38,1x19,05x1,39

black

HVR40 Stiftwanne

170-109-00000

34,93x19,05 x 1,65

black

SLPCC001-C05

170-110-00000

44,45x19,05x1,65

black

SLPCC001-C06

170-111-00000

53,98x19,05x1,65

black

SLPCC001-C07

170-115-00000

31,75x20,0x1,65

black

H1S101-92SPC0B1-A

170-116-00000

17,45x19,05x1,52

black

M&I

170-127-00000

3,48x6x0,71

black

SMB (f)

Material and plating

Parts

Material

Plating

Protection cap

PVC Shore A 65±5

Environmental data

Temperature range

-45°C to +85°C

RoHS

compliant

Draft

Date

Approved

Date

Rev.

Engineering change number

Name

Date

F. Fraunhofer

22.01.09

B. Huppenberger

11.01.17

h00

17-0004

P. Schiebeck

11.01.17
