Figure 1. Relative intensity vs. wavelength.

Electrical/Optical Characteristics at TA = 25°C

Sym.

Description

HLMP-R100

HLMP-0301

HLMP-0401

HLMP-0504

Units

Test

Conditions

Min. Typ. Max. Min. Typ. Max. Min. Typ. Max. Min. Typ. Max.

q1/2

Included Angle

Between Half

Luminous

Intensity Points

100

Deg.

Note 1.

Fig. 6

Peak Wavelength

645

635

583

565

Measure-

ment at

Peak

Dominant

Wavelength

637

626

585

569

Note 2.

Dl1/2

Spectral Line

Halfwidth

Speed of Response

500

Capacitance

VF = 0;

f = 1 MHz

qJ-PIN Thermal Resistance

260

°C/W

Junction

to Cathode

Lead

Forward Voltage

1.8

2.2

1.9

2.6

2.1

2.6

2.2

3.0

IF = 20 mA

Figure 2.

Reverse Breakdown

Voltage

5.0

IR = 100 μA

Luminous Efficacy

145

500

595

lm/W

Note 3.

Notes:

q1/2 is the off-axis angle at which the luminous intensity is half the axial luminous intensity.

2. The dominant wavelength,

ld, is derived from the CIE chromaticity diagram and represents the single wavelength which defines the color of the

device.

3. Radiant intensity, Ie, in watts/steradian, may be found from the equation Ie = Iv/hv, where Iv is the luminous intensity in candelas and hv is the

luminous efficacy in lumens/watt.

HIGH EFFICIENCY RED

WAVELENGTH – nm

1.0

0.5

500

550

600

650

700

750

YELLOW

GREEN

TA = 25 °C

AlGaAs RED
