Electrical characteristics
LED6000
10/49
DocID027777 Rev 2
Dimming
VDIMH
DIM rising threshold
1.23
1.7
V
VDIML
DIM falling threshold
0.75
1.00
V
VDIMPD DIM pull-down current
VDIM = 2 V
0.5
1.5
2.5
A
TDIMTO
Dimming timeout
(3)
42
ms
Thermal shutdown
TSHDWN
Thermal shutdown
temperature
(3)
170
°C
THYS
Thermal shutdown
hysteresis
(3)
15
°C
1. Specifications referred to TJ from -40 to +125 °C. Specifications in the -40 to +125 °C temperature range are assured by
design, characterization and statistical correlation.
2. Parameter tested in static condition during testing phase. Parameter value may change over dynamic application condition.
3. Not tested in production.
Table 5. Electrical characteristics (continued)
Symbol
Parameter
Test condition
Min.
Typ.
Max. Unit
