CS7654
7
RECOMMENDED OPERATING CHARACTERISTICS
ABSOLUTE MAXIMUM RATINGS
WARNING: Operation at or beyond these limits may result in permanent damage to the device.
Normal operation is not guaranteed at these extremes.
Parameter
Symbol
Min
Typ
Max
Unit
Power Supply Voltage
VDD
4.5
5.0
5.5
V
Ground to Ground Voltage Differential
-
-
10
mV
Digital Input Rise/Fall Time
-
-
10
ns
CLKIN Level Setup to CLKIN2X Rising (non-interpolated)
tS2
8-
-
ns
CLKIN Level Hold after CLKIN2X Rising (non-interpolated)
tH2
8-
-
ns
Digital Input Voltage Range
0
-
VDD
V
Operating Temperature Range
TA
0-
70
°C
Parameter
Symbol
Min
Max
Unit
Power Supply Voltage
VDD
-0.3
6.0
V
Digital Input Voltage Range
GND - 0.3
VDD + 0.3
V
Forced Digital Output Current
-
50
mA
Sustained Digital Output Voltage
GND - 0.3
VDD + 0.3
V
Output Short Circuit Current
-
-
mA
Operating Temperature Range
TA
070
°C
Lead Solder Temperature (10 s duration)
-
+260
°C
Storage Temperature Range
-65
+160
°C
