ADAV801
Rev. A | Page 12 of 60
FREQUENCY (kHz)
0
–50
–100
–150
0
192
384
576
768
Figure 9. DAC Composite Filter Response, 96 kHz
FREQUENCY (kHz)
0
–50
–100
–150
024
48
72
96
Figure 10. DAC Pass-Band Filter Response, 96 kHz
FREQUENCY (kHz)
0.10
0.05
0
–0.05
–0.10
024
48
72
96
Figure 11. DAC Filter Ripple, 96 kHz
FREQUENCY (kHz)
0
–50
–100
–150
–200
0
384
768
1152
1536
Figure 12. DAC Composite Filter Response, 192 kHz
FREQUENCY (kHz)
0
–2
–4
–6
–8
–10
48
64
80
96
Figure 13. DAC Pass-Band Filter Response, 192 kHz
FREQUENCY (kHz)
0.50
0.40
0.30
0.20
0.10
0.00
–0.10
–0.30
–0.40
–0.20
–0.50
0
8
16
32
64
Figure 14. DAC Filter Ripple, 192 kHz
