AD7687

Data Sheet

Rev. E | Page 8 of 26

ABSOLUTE MAXIMUM RATINGS

Table 6.

Parameter

Rating

Analog Inputs

IN+1, IN−1

GND − 0.3 V to VDD + 0.3 V

or ±130 mA

REF

GND − 0.3 V to VDD + 0.3 V

Supply Voltages

VDD, VIO to GND

−0.3 V to +7 V

VDD to VIO

±7 V

Digital Inputs to GND

−0.3 V to VIO + 0.3 V

Digital Outputs to GND

−0.3 V to VIO + 0.3 V

Storage Temperature Range

−65°C to +150°C

Junction Temperature

150°C

Lead Temperature Range

JEDEC J-STD-20

See the Analog Input section.

Stresses at or above those listed under Absolute Maximum

Ratings may cause permanent damage to the product. This is a

stress rating only; functional operation of the product at these

or any other conditions above those indicated in the operational

section of this specification is not implied. Operation beyond

the maximum operating conditions for extended periods may

affect product reliability.

THERMAL RESISTANCE

θJA is specified for the worst-case conditions, that is, a device

soldered in a circuit board for surface-mount packages.

Table 7. Thermal Resistance

Package Type

θJA

θJC

Unit

10-Lead LFCSP

2.96

°C/W

10-Lead MSOP

200

°C/W

ESD CAUTION
