ADRF6614

Data Sheet

Rev. 0 | Page 10 of 61

ABSOLUTE MAXIMUM RATINGS

Table 8.

Parameter

Rating

Supply Voltage (VCC1, VCC2, VCC3,

VCC4, VCC5, VCC6, VCC7, VCC8, VCC9,

VCC10, VCC11, VCC12, IFOUT1+,

IFOUT1−, IFOUT2+, IFOUT2−)

−0.5 V to +5.5 V

Digital Input/Output (SCLK, SDIO, CS)

−0.3 V to +3.6 V

RFINx

20 dBm

EXTVCOIN+, EXTVCOIN−

13 dBm

Maximum Junction Temperature

150°C

Operating Temperature Range

−40°C to +85°C

Storage Temperature Range

−65°C to +150°C

Stresses at or above those listed under Absolute Maximum

Ratings may cause permanent damage to the product. This is a

stress rating only; functional operation of the product at these

or any other conditions above those indicated in the operational

section of this specification is not implied. Operation beyond

the maximum operating conditions for extended periods may

affect product reliability.

THERMAL RESISTANCE

θJC is specified for the worst case conditions, that is, a device

soldered in a circuit board for surface-mount packages.

Table 9. Thermal Resistance

Package Type

θJC

Unit

48-Lead LFCSP

1.62

°C/W

ESD CAUTION
