TSV7721 datasheet(5/40 Pages) STMICROELECTRONICS

5 / 40 page

Absolute maximum ratings and operating conditions

Table 4. Absolute maximum ratings

Symbol

Parameter

Value

Unit

VCC

Supply voltage (referred to VCC- pin) (1)

-0.3 to 6.0

Vid

Differential input voltage (2)

± VCC

VIN

Input pins input voltage (3)

VCC- - 0.3 V to VCC+ + 0.3 V

IIN

Input pins input current (4)

± 10

Tstg

Storage temperature

-65 to 150

°C

Rth-ja

Thermal resistance junction-to-ambient (5)

°C / W

SOT23-5

250

DFN8 (2 mm x 2 mm)

MiniSO8

127

MiniSO10

113

SO8

113

Maximum junction temperature

150

°C

ESD

HBM: human body model (6)

CDM: charged device model (7)

1.5

1. All voltage values, except differential voltage, are with respect to VCC- pin.

2. The differential voltage is the non-inverting input terminal with respect to the inverting input terminal.

3. Vcc - Vin must not exceed 6 V, Vin must not exceed 6 V.

4. Input current must be limited by a resistor in series with the inputs.

5. Rth are typical values.

6. Human body model: the test HBM is done in accordance with the standards ESDA-JS-001-2017 and Q100-002

7. Charged device model: the test CDM is done in accordance with the standards ESDA-JS-002-2018 and Q100-011

Table 5. Operating conditions

Symbol

Parameter

Min.

Max.

Value

VCC

Supply voltage

1.8

5.5

Vicm

Common-mode input voltage range

VCC- – 0.1

VCC+ – 1.1

Toper

Operating free air temperature range

-40

125

°C

TSV7721, TSV7722, TSV7723

Absolute maximum ratings and operating conditions

DS13614 - Rev 3

page 5/40
