NXP Semiconductors

PTN3355

Low power DP to VGA adapter with integrated 1 : 2 VGA switch

15. Packing information

SOT618-1

HVQFN40; Reel dry pack, SMD, 13”; Q2/T3 turn product orientation

Orderable part number ending ,528 or MP; Ordering code (12NC) ending 528

15.1 Packing method

[1]

d = reel diameter; w = tape width.

Fig 10. Dry reel pack for SMD

Table 23.

Dimensions and quantities

Reel dimensions

 w (mm) [1]

SPQ/PQ (pcs)

Reels per box

Outer box dimensions

 w  h (mm)

330

 16

4000

339

 335  43

Relative humidity

indicator

Barcode label

Bag

ESD print

Moisture caution

Dry-agent

Cover tape

Carrier tape

Barcode label

ESD embossed

Reel assembly

Printed plano box

Guard band

Tape

aaa-005677

Drypack ID sticker

Space for additional

label

Preprinted ESD

warning

Barcode label

QA seal

Printed plano box
