PTN3355
Low power DP to VGA adapter with integrated 1 : 2 VGA switch
15.2 Product orientation
15.3 Carrier tape dimensions
Pin 1 is in quadrant 2.
Fig 11. Product orientation in carrier tape
aaa-006538
pin 1
Fig 12. Carrier tape dimensions
Table 24.
Carrier tape dimensions
In accordance with IEC 60286-3.
A0 (mm)
B0 (mm)
K0 (mm)
T (mm)
P1 (mm)
W (mm)
6.3
6.3
1.1
-
12
16
K0
001aao148
A0
4 mm
T
P1
B0
W
direction of feed
