36 / 41 page

Date

Revision

Changes

20-May-2022

Updated:

•

Section Features, Section 1 Description, Section 2.2 Serial data (SDA),

Section 2.3 Chip enable (E2, E1, E0), Section 2.5 VSS (ground), Section 4.2 Stop

condition, Section 4.5 Device addressing, Section 5.1.3 Minimizing write delays

by polling on ACK, Section 5.2 Read operations, Section 9.1 UFDFPN5 (DFN5)

package information, Section 9.3 SO8N package information, Section 9.2 TSSOP8

package information, Section 9.4 UFDFPN8 (DFN8) package information

•

note in Figure 3

•

Figure 4. Block diagram

•

Table 4. Absolute maximum ratings, Table 10. Cycling performance,

Table 11. Memory cell data retention, Table 12. DC characteristics (M24C01/02-W),

Table 13. DC characteristics (M24C01/02-R), Table 14. DC characteristics (M24C02-

F), Table 15. 400 kHz AC characteristics (I2C Fast-mode), Table 16. 100 kHz AC

characteristics (I2C standard-mode), Table 21. Ordering information scheme

Removed PDIP8 package

M24C01/02-W M24C01/02-R M24C02-F

DS9398 - Rev 7

page 36/41
