background image
32
Surge Protection
Busbars Z-GV-U/
Models
• Busbars Z-GV-U/ permit to implement customary SPD combinations
• Suitable for SPI-..., SPB-D-125
• The rated cross-section of Z-GV-U/ is 16 mm2
• The busbars must be cut to length in some cases
Marking Label SPI-BZS-L/N/PE
• Can be affixed to SPI-..., SPB-D-125
• Size 7 x 17mm
• Colour: white
Technical Data
Electrical
Rated voltage
230/400 V, 50/60 Hz
Rated current
63 A
Mechanical
Busbar cross section
16 mm2 Cu
Busbars ZV-KSBI
Models
• Busbars ZV-KSBI permit to implement customary SPD combinations
• Suitable for SPB-..., SPC-..., Z-D63
• The rated cross-section of ZV-KSBI is 16 mm2
• The busbars must be cut to length in some cases
Technical Data
Electrical
Rated voltage
230/400 V, 50/60 Hz
Rated current
63 A
Mechanical
Busbar cross section
16 mm2 Cu
