3 / 16 page

AD8353

Rev. B | Page 3 of 16

SPECIFICATIONS

VS = 3 V, TA = 25°C, 100 nH external inductor between RFOUT and VPOS, ZO = 50 Ω, unless otherwise noted.

Table 1.

Parameter

Conditions

Min

Typ

Max

Unit

OVERALL FUNCTION

Frequency Range

2700

MHz

Gain

f = 900 MHz

19.8

f = 1.9 GHz

17.7

f = 2.7 GHz

15.6

Delta Gain

f = 900 MHz, −40°C ≤ TA ≤ +85°C

−0.97

f = 1.9 GHz, −40°C ≤ TA ≤ +85°C

−1.15

f = 2.7 GHz, −40°C ≤ TA ≤ +85°C

−1.34

Gain Supply Sensitivity

VPOS ± 10%, f = 900 MHz

0.04

dB/V

f = 1.9 GHz

−0.004

dB/V

f = 2.7 GHz

−0.04

dB/V

Reverse Isolation (S12)

f = 900 MHz

−35.6

f = 1.9 GHz

−34.9

f = 2.7 GHz

−30.3

RF INPUT INTERFACE

Pin RFIN

Input Return Loss

f = 900 MHz

22.3

f = 1.9 GHz

20.9

f = 2.7 GHz

11.2

RF OUTPUT INTERFACE

Pin RFOUT

Output Compression Point

f = 900 MHz, 1 dB compression

9.1

dBm

f = 1.9 GHz

8.4

dBm

f = 2.7 GHz

7.6

dBm

Delta Compression Point

f = 900 MHz, −40°C ≤ TA ≤ +85°C

−1.46

f = 1.9 GHz, −40°C ≤ TA ≤ +85°C

−1.17

f = 2.7 GHz, −40°C ≤ TA ≤ +85°C

−1

Output Return Loss

f = 900 MHz

26.3

f = 1.9 GHz

16.9

f = 2.7 GHz

13.3

DISTORTION/NOISE

Output Third-Order Intercept

f = 900 MHz, ∆f = 1 MHz, PIN = −28 dBm

23.6

dBm

f = 1.9 GHz, ∆f = 1 MHz, PIN = −28 dBm

20.8

dBm

f = 2.7 GHz, ∆f = 1 MHz, PIN = −28 dBm

19.5

dBm

Output Second-Order Intercept

f = 900 MHz, ∆f = 1 MHz, PIN = −28 dBm

31.6

dBm

Noise Figure

f = 900 MHz

5.3

f = 1.9 GHz

f = 2.7 GHz

6.8

POWER INTERFACE

Pin VPOS

Supply Voltage

2.7

3.3

Total Supply Current

Supply Voltage Sensitivity

15.3

mA/V

Temperature Sensitivity

−40°C ≤ TA ≤ +85°C

μA/°C
