Data Sheet

ADM3053

Rev. A | Page 7 of 20

ABSOLUTE MAXIMUM RATINGS

TA = 25°C, unless otherwise noted. All voltages are relative to

their respective ground.

Table 6.

Parameter

Rating

VCC

−0.5 V to +6 V

VIO

−0.5 V to +6 V

Digital Input Voltage, TxD

−0.5 V to VIO + 0.5 V

Digital Output Voltage, RxD

−0.5 V to VIO + 0.5 V

CANH, CANL

−36 V to +36 V

VREF

−0.5 V to +6 V

Operating Temperature Range

−40°C to +85°C

Storage Temperature Range

−55°C to +150°C

ESD (Human Body Model)

3 kV

Lead Temperature

Soldering (10 sec)

300°C

Vapor Phase (60 sec)

215°C

Infrared (15 sec)

220°C

θJA Thermal Impedance

53°C/W

TJ Junction Temperature

130°C

Stresses above those listed under Absolute Maximum Ratings

may cause permanent damage to the device. This is a stress

rating only; functional operation of the device at these or any

other conditions above those indicated in the operational

section of this specification is not implied. Exposure to absolute

maximum rating conditions for extended periods may affect

device reliability.

Table 7. Maximum Continuous Working Voltage1

Parameter

Max

Unit

Reference Standard

AC Voltage

Bipolar Waveform

424

V peak

50 year minimum

lifetime

Unipolar Waveform

Basic Insulation

560

V peak

Maximum approved

working voltage per

VDE 0884 Part 2

DC Voltage

Basic Insulation

560

V peak

Maximum approved

working voltage per

VDE 0884 Part 2

1 Refers to continuous voltage magnitude imposed across the isolation

barrier. See the Insulation Lifetime section for more details.

ESD CAUTION
