Data Sheet
ADM3053
Rev. A | Page 17 of 20
TYPICAL APPLICATIONS
Figure 32 is an example circuit diagram using the ADM3053.
CAN
CONTROLLER
3.3V/5V
SUPPLY
100nF
10nF
100nF
10nF
CANH
CANL
RT
BUS
CONNECTOR
5V
SUPPLY
100nF
10µF
10µF
100nF
RS
ADM3053
TxD
RxD
ISOLATION
BARRIER
GND1
GND2
LOGIC SIDE
BUS SIDE
ENCODE
DECODE
DECODE
ENCODE
OSCILLATOR
RECTIFIER
REGULATOR
VISOOUT
DIGITAL ISOLATION iCoupler
isoPowerDC-TO-DC CONVERTER
VIO
VISOIN
RS
CANH
CANL
VREF
REFERENCE
VOLTAGE
RECEIVER
CAN TRANSCEIVER
TxD
RS
RxD
VREF
GND2
VCC
SLOPE/
STANDBY
DRIVER
PROTECTION
VCC
Figure 32. Example Circuit Diagram Using the ADM3053
