SSM2518

Data Sheet

Rev. A | Page 8 of 48

ABSOLUTE MAXIMUM RATINGS

Absolute maximum ratings apply at 25°C, unless otherwise noted.

Table 6.

Parameter

Rating

PVDD Supply Voltage

−0.3 V to +6 V

DVDD Supply Voltage

−0.3 V to +3.6 V

Input Voltage (ADDR, MCLK, BCLK, LRCLK,

SDATA, SAMOD Pins)

−0.3 V to +3.6 V

Input Voltage (SD, SDA, and SCL Pins)

−0.3 V to +6 V

ESD Susceptibility

4 kV

Storage Temperature Range

−65°C to +150°C

Operating Temperature Range

−40°C to +85°C

Junction Temperature Range

−65°C to +165°C

Lead Temperature (Soldering, 60 sec)

300°C

Stresses abovethose listed under Absolute Maximum Ratings

may cause permanent damage to the device. This is a stress

rating only; functional operation of the device at these or any

other conditions above those indicated in the operational

section of this specification is not implied. Exposure to absolute

maximum rating conditionsfor extended periodsmay affect

device reliability.

THERMAL RESISTANCE

θJA is specified for the worst-case conditions, that is, a device

soldered in a circuit board for surface-mount packages.

Table 7. Thermal Resistance

Package Type

θJA

Unit

16-ball, 2 mm × 2 mm WLCSP

°C/W

20-lead, 4.0 mm × 4.0 mm LFCSP

°C/W

ESD CAUTION
