(6/25)

INDUC

001-01 / 20130929 / inductor_decoupling_mlz_en.fm

• All specifications are subject to change without notice.

MLZ series

MLZ1005 Type

ELECTRICAL CHARACTERISTICS

CHARACTERISTICS SPECIFICATION TABLE

1 Current assumed when inductance ratio has decreased by 50% max..

2 Current assumed when temperature has risen to 20°C max. (reference value).

Operating temperature environment at this time: 105°C max.

The " □□□ " of the Part Number contains the internal code.

○ Measurement equipment

＊ Equivalent measurement equipment may be used.

Type

L measuring conditions

DC resistance

(

: )±30%

Rated current1

(mA)

Rated current2

(mA)

Part No.

(μH)

Tolerance

Frequency

(MHz)

Current

(mA)

Large

current

0.47

±20%

0.1

0.20

120

500

MLZ1005MR47WT

0.68

±20%

0.1

0.30

110

450

MLZ1005MR68WT

1.00

±20%

0.1

0.35

100

450

MLZ1005M1R0WT

1.50

±20%

0.1

0.50

350

MLZ1005M1R5WT

2.20

±20%

0.1

0.55

350

MLZ1005M2R2WT

Measurement item

Product No.

Manufacturer

4294A+16034G

Agilent Technologies

DC resistance

Type-7561

Yokogawa
