DS1135-L

6 of 6

TERMINOLOGY

Period: The time elapsed between the leading edge of the first pulse and the leading edge of the

following pulse.

tWI(Pulse Width): The elapsed time on the pulse between the 1.5V point on the leading edge and the

1.5V point on the trailing edge or the 1.5V point on the trailing edge and the 1.5V point on the leading

edge.

tRISE (Input Rise Time): The elapsed time between the 20% and the 80% point on the leading edge of the

input pulse.

tFALL (Input Fall Time): The elapsed time between the 80% and the 20% point on the trailing edge on the

input pulse.

tPLH (Time Delay, Rising): The elapsed time between the 1.5V point on the leading edge of the input

pulse and the 1.5V point on the leading edge of the output pulse.

tPHL (Time Delay, Falling): The elapsed time between the 1.5V point on the falling edge of the input

pulse and the 1.5V point on the falling edge of the output pulse.

ORDERING INFORMATION

DS1135L

PACKAGE TYPE: U = µSOP

(118MIL)

Z = SO (150MIL)

Dash

Delay (NS)

Number

Time
