TPS51362

www.ti.com

SLUSBB6A – FEBRUARY 2013 – REVISED JUNE 2013

REVISION HISTORY

NOTE: Page numbers of current version may differ from previous versions.

Changes from Original (February 2013) to Revision A

Page

•

Added MIN and MAX values to IOCLspec in the Elec Characteristics table .......................................................................... 5

•

Changed the Functional Block Diagram VREFIN signal line identifier on the UV-detect device from "VREFIN – 32%" to

"VREFIN – 34%". Changed signal line identifier on the high-side comparator from "VREFIN+ 8/20%" to "VREFIN+ 20%".

Changed the high-side device symbol from hysteresis to a comparator. Changed signal line identifier on the low-

side device from "VREFIN– 8/32%" to "VREFIN– 8/34%. ........................................................................................................... 8

•

Added Land pads for a 0.1-µF capacitor between VIN and PGND of the TPS51362 Design Layout figure. .................... 19

•

Added a 0.1-µF capacitor symbol between VIN and PGND of the Design 1: Application Schematic. ............................... 20

•

Changed LOUT inductor part number from PIMB063T to PIMB063T-R68MS-63 in Design 1: List of Materials table. ....... 20
