background image
4 25/07/2016
ICPLW50L
ISOCOM
COMPONENTS
DC93196
ELECTRICAL CHARACTERISTICS (V
CC = 2.7 to 24V, IF = 3mA and TA = -40°C to 105°C,
unless otherwise specified)
SWITCHING
Parameter
Symbol
Test Condition
Min
Typ.
Max
Unit
Propagation Delay Time
to High Output Level
tPLH
f = 10kHz, Duty Cycle = 50%,
IF = 3mA, VCC = 3.3V,
RL=1.8KΩ, CL = 15pF,
VTHLH = 2V
0.4
1.4
μs
f = 10kHz, Duty Cycle = 50%,
IF = 3mA, VCC = 5.0V,
RL=2.9KΩ, CL = 15pF,
VTHLH = 2V
0.4
1
Propagation Delay Time
to Low Output Level
tPHL
f = 10kHz, Duty Cycle = 50%,
IF = 3mA, VCC = 3.3V,
RL=1.8KΩ, CL = 15pF,
VTHHL = 1.5V
0.3
1
f = 10kHz, Duty Cycle = 50%,
IF = 3mA, VCC = 5.0V,
RL=2.9KΩ, CL = 15pF,
VTHHL = 1.5V
0.3
1
Pulse Width Distortion
|tPHL - tPLH| for any given
device
PWD
f = 10kHz, Duty Cycle = 50%,
IF = 3mA, VCC = 3.3V,
RL=1.8KΩ, CL = 15pF,
VTHLH = 2V
VTHHL = 1.5V
0.1
1.4
f = 10kHz, Duty Cycle = 50%,
IF = 3mA, VCC = 5.0V,
RL=2.9KΩ, CL = 15pF,
VTHLH = 2V
VTHHL = 1.5V
0.1
1
Common Mode
Transient Immunity at
High Output Level
CMH
IF = 0mA,
VCC = 3.3V or 5V,
VCM = 1500V p-p
RL=1.8KΩ or 2.9kΩ,
TA = 25°C
15
kV/μs
Common Mode
Transient Immunity at
Low Output Level
CML
IF = 3mA,
VCC = 3.3V or 5V,
VCM = 1500V p-p,
RL=1.8KΩ or 2.9kΩ,
TA = 25°C
15
kV/μs
