ø30 Series Accessories and Replacement Parts ø30

Terminal Covers

Terminal Cover

ø30 Series Switches & Pilot Lights

N-VL2

N-VL3

N-VL4

APN-PVL

APD-PVL

Use of termi-

nal covers

increases the

depth by the

dimensions

below.

Terminal Cover

Pilot Light

APN, APNE, UPQN, UPQNE

Full Voltage

+5.0 mm

Pilot Light

APD, APDE

+5.2 mm

Pilot Light

APN, APNE, APD, APDE,

UPQN, UPQNE

Transformer

DC-DC Converter

+2.7 mm

Pushbutton

ABN, ABD, AON, AOD, AVN,

ABGD, AJN, ABFD, ATN,

AOFD, UBQN, AVD, UOQN,

AJD, UWQN, AZD, ABBN,

AYD, ABBS (ø25)

Selector Switch

ASN, ASD, ASTN

Selector Pushbutton

ABN, ASBD

1 contact block

+0 mm

2 contact blocks

2 pieces

3 contact blocks

2 pieces

4 contact blocks

2 pieces

Illuminated Pushbutton

ALN, ALD, ALNE, ALDE,

AOLN, AOLD, AOLNE,

AOLDE, ALGN, ALGD,

ALGNE, ALGDE, AOLGN,

AOLGDE, ALFN, ALFD,

ALFNE, ALFDE, AOLFN,

AOLFD, AOLFNE, AOLFDE,

AVLN, AVLD, AVLNE, AVLDE,

AJLN, AJLD, AJLNE, AJLDE,

ULQN, UOLQN

Illuminated Selector Switch

ASLN, ASLD

Push-to-Check Pilot Light

APN1

∗∗P

Full Voltage

2 pieces

+4.5 mm

Transformer

DC-DC Converter

+1.5 mm

Ordering Terminal Covers

•Whenorderingterminalcovers,specifythePartNo.andthequantity.

38.4H × 22W 38H × 30.4W 38.4H × 24W

38H × 46W

37H × 44W

Terminal Cover

(N-VL2)

Terminal Cover

(N-VL2)

ø30
