Series MB2000

Large Bushing Miniature Pushbuttons

C92

C

www.nkkswitches.com

Cap Colors

For Shroud

A

Black

B

White

C

Red

F

Green

G

Blue

H

Gray

CUSTOM ASSEMBLY ORDERING EXAMPLE

C

4

MB2011

Poles & Circuits

2011

SPDT

ON

(ON)

2065

SPDT

ON

ON

2061

DPDT

ON

(ON)

2085

DPDT

ON

ON

4-pole available

( ) = Momentary

SB1W01

Mounter Colors

For Shroud

A

Black

B

White

H

Gray

Mounter Shapes

For Shroud

4

Round

5

Rectangular

The MB2000 pushbutton series offers flexibility to accommodate a variety of applications. Using a basic large bushing model,

different accessories can be assembled onto the switch to achieve the mounting variations shown on the following two pages.

A

Cap Colors

For Snap-In

A

Black

B

White

C

Red

F

Green

Round Shroud

MB2011SB1W01-4C-A

See custom assemblies on following pages.

Rectangular Shroud

MB2011SB1W01-5C-A

These switches have: • 12mm diameter threaded bushing with keyway

• Silver contacts

• 6-Amp rating

• Solder lug terminals

Other 12mm bushing options can be used; see details in preceding Large Bushing Ordering tables.
