MB2000 Datasheet(PDF) 8 Page - Nihon Kaiheiki Industry Co. Ltd. |
|
|
|||||||||||||||||||||||||||||
MB2000 Datasheet(HTML) 8 Page - Nihon Kaiheiki Industry Co. Ltd. |
|
|
8 / 23 page  Series MB2000 Bushing Mount Miniature Pushbuttons C79 C www.nkkswitches.com HARDWARE AT516 O-ring for Splashproof Bushing 1 included with each splashproof model Material: Nitrile butadiene rubber AT509 Lockwasher 1 included with each switch (not with splashproof models) Material: Steel with Zinc/Chromate Optional Mounting Collars/Conical Nuts AT4042H for Inch AT4042M for Metric Boot for Alternate Material: Silicone rubber Dimension A = Cap Height .091” (2.3mm) for Momentary with Plunger Code S .157” (4.0mm) for Alternate with Plunger Code S .142” (3.6mm) for Momentary & Alternate with Plunger Code L AT507H for Inch AT507M for Metric Locking Ring Material: Steel with Zinc/Chromate (9.0) .354 (1.5) .059 (1.7) .067 (0.8) .031 (6.4) Dia .252 (10.2) Dia .402 (0.5) .020 Standard Hardware Optional Hardware AT4041H for Inch AT4041M for Metric Boot for Momentary Material: Silicone rubber Optional Splashproof Boots for S Plunger Operating Life 100,000 Boots for momentary devices are accompanied by a threaded adaptor which extends the length of the plunger. Operating Life 30,000 AT512CH for Inch AT512CM for Metric Conical nut Used with .394” (10.0mm) Diameter Cap (cap code C) Material: Brass with chrome plating AT512H for Inch AT512M for Metric Conical Nut Used with .315” (8.0mm) Diameter Cap (cap code B) Material: Brass with chrome plating M6 P0.75 or 1/4-40 Thd M2.3 P0.4 AT513H for Inch AT513M for Metric Hexagon Nut 2 included with each switch (1 with splashproof models) Material: Brass with Nickel plating (9.63) Dia .379 (6.07) Dia .239 (10.0) .394 (8.5) .335 (13.0) Dia .512 (10.5) Dia .413 (4.0) Max .157 A A (10.0) .394 (10.0) .394 (12.2) Dia .480 (4.0) Max .157 A A (14.0) Dia .551 (10.8) .425 (8.5) .335 (10.0) .394 (4.9) Dia .193 (6.0) Dia .236 (4.0) Max .157 (3.5) Min .138 (10.8) .425 (8.5) .335 (10.0) .394 (4.9) Dia .193 (6.0) Dia .236 (4.0) Max .157 (3.5) Min .138 (1.78) .070 (5.5) or .229 (6.0) Dia or .250 (12.0) Dia .472 (2.0) .079 (8.0) .315 1/4-40 Thd or M6 P0.75 Optional Conical Nuts fit with all 8.5mm bushing options except the D3 & S2 bushings. |
|
|
