MB2000 Datasheet(PDF) 3 Page - Nihon Kaiheiki Industry Co. Ltd. |
|
|
|||||||||||||||||||||||||||||
MB2000 Datasheet(HTML) 3 Page - Nihon Kaiheiki Industry Co. Ltd. |
|
|
3 / 23 page  Series MB2000 Bushing Mount Miniature Pushbuttons C74 C www.nkkswitches.com Cap Colors A Black B White C Red E Yellow F Green G Blue H Gray TYPICAL SWITCH ORDERING EXAMPLE A 2011 C MB SPDT ON-(ON) Circuit Solder Lug Terminals Poles & Circuits 2011 SPDT ON (ON) 2065 SPDT ON ON 2061 DPDT ON (ON) 2085 DPDT ON ON 2181 4PDT ON (ON) 2185 4PDT ON ON ( ) = Momentary S DESCRIPTION FOR TYPICAL ORDERING EXAMPLE MB2011SS1W01-CA Caps B .315” (8.0mm) Diameter C .394” (10.0mm) Diameter Contact Materials & Ratings W Silver Rated 6A @ 125V AC & 3A @ 250V AC G Gold Rated 0.4VA max @ 28V AC/DC max A Gold over Silver Rated 6A @ 125V AC & 0.4VA max @ 28V AC/DC max Plunger for Screw-on Caps S1 W 01 Plunger Types S Plunger for Screw-on Caps L Plunger for Snap-on Caps Bushings S1 .335” (8.5mm) Threaded with Keyway S2 .335” (8.5mm) Smooth with Keyway S4 .335” (8.5mm) Metric Threaded with Keyway D1 .335” (8.5mm) Threaded with D-Flat D3 .335” (8.5mm) Threaded Splashproof without Keyway Terminals 01 Solder Lug 02 Quick Connect 03 .250” (6.35mm) Straight PC 05 .425” (10.8mm) Wirewrap 06 .750” (19.05mm) Wirewrap 07 .964” (24.5mm) Wirewrap 08 1.062” (27.0mm) Wirewrap Black .394” (10.0mm) Diameter Cap Silver Contacts with 6-Amp Rating .335” (8.5mm) Threaded Bushing with Keyway IMPORTANT: Switches are supplied without UL, cULus & CSA marking unless specified. UL, cULus & CSA recognized only when ordered with marking on the switch. Specific models, ratings, & ordering instructions are noted on the General Specifications page. |
|
|
