 37 / 40 page
background image
DocID023924 Rev 3
37/40
M24C08-W M24C08-R M24C08-F
Package mechanical data
39
Table 23. Thin M24C08-FCT5TP/S WLCSP package data
Symbol
millimeters
inches(1)
1. Values in inches are converted from mm and rounded to four decimal digits.
Typ
Min
Max
Typ
Min
Max
A
0.300
0.270
0.330
0.0118
0.0106
0.0130
A1
0.100
–
–
0.0039
–
–
A2
0.200
–
–
0.0079
–
–
b
0.160
–
–
0.0063
–
–
D
1.215
–
1.340
0.0478
–
0.0528
E
1.025
–
1.150
0.0404
–
0.0453
e
0.400
–
–
0.0157
–
–
e1
0.693
–
–
0.0273
–
–
e2
0.346
–
–
0.0136
–
–
F
0.313
–
–
0.0123
–
–
G
0.261
–
–
0.0103
–
–
N5
aaa
0.110
–
–
0.0043
–
–
bbb
0.110
–
–
0.0043
–
–
ccc
0.110
–
–
0.0043
–
–
ddd
0.060
–
–
0.0024
–
–
eee
0.060
–
–
0.0024
–
–
